4K 1000fps Camera van $100.000, de Phantom Flex 4k

RG Leestijd: 2 minuten
Illustratie voor: 4K 1000fps Camera van $100.000, de Phantom Flex 4k


Met de Phantom Flex 4k maak je de vetste shots en dat mag ook wel voor +-$100.000. Je hebt wel een paar TB aan opslagruimte nodig wil je een uurtje filmen. Wij willen hem ieder geval hebben, verjaardagscadeautje please?!

Bekijk de beelden hier onder en oordeel zelf!

Resolution / Max Frame Rate
4096 x 2304 (max res) – 940 fps
4096 x 2160 (4K standard) – 1000 fps
2048 x 1080 – 2000 fps
1280 x 720 – 3000 fps

Pixel Size
6.75 micron

Sensor Size
27.7 x 15.5mm

Sensor @ 1080p:
13 x 7.3mm

Lens Mount
PL (standard), Canon EOS, Nikon F/G
Recording Media

Phantom CineMag IV
Size
11.5 x 5.0 x 7.9 in (LxWxH);
29.2 x 14 x 20 cm

Weight
14 lbs (6.3 kg) w/o lens or viewfinder

Power Input
1x 3-pin 24V input (+14-28vdc)

Battery Mount
Integrated standard battery back
12V Power Aux Outputs

1x 2-pin Lemo,
1x 4-pin Hirose for monitor
24V Power Aux Outputs
2x 3-pin Fischer w/ R/S

Ethernet
1x 8-pin Fischer for optional software
operation & file download

Remote
1x 5-pin Fischer for RS232 & +12-24V DC

Bluetooth
1x Bluetooth antenna for remote operation (up to 100m)

HD-SDI
3x 3G HD-SDI BNC
1additional SDI output for viewfinder,
1 return, includes Genlock support

Sync
1 Fischer: F-sync, Time code in & out, trigger

Viewfinder
1 selectable Fischer or Hirose for component video, and 1x 3G HD-SDI BNC for SDI-based viewfinders (including Phantom OLED HD VF)
